| MODEL | ZF9 | ZF18 | ZF55 |
| Power source V | 220V/60Hz-3 phases 220V/50Hz-3 phases 380V/60Hz-3 phases 380V/50Hz-3 phases |
220V/60Hz-3 phases 220V/50Hz-3 phases 380V/60Hz-3 phases 380V/50Hz-3 phases |
220V/60Hz-3 phases 220V/50Hz-3 phases 380V/60Hz-3 phases 380V/50Hz-3 phases |
| Rated power Hp ( kw ) | 0.12 - ( 0.09 ) | 0.25 - ( 0.18 ) | 0.73- ( 0.55 ) |
| Rated current Amp | 0.29 | 0.48 | 1.2 |
| Vibration amplitude Inch ( mm ) | 0.09 - ( 2.4 ) | 0.12 - ( 3.2 ) | 0.19 - ( 5 ) |
| Centrifugal force Kn | 1.0 | 1.4 | 5.0 |
| Overall dimensions Inch ( mm ) | 8.7 x 5.8 x 5.7 - ( 220 x 148 x 145 ) | 8.8 x 6.9 x 5.9 - ( 225 x 175 x 150 ) | 12.2 x 8.7 x 7.5 - ( 310 x 220 x 190 ) |
| Weight Lb ( kg ) | 18.7 - ( 8.5 ) | 24.2 - ( 11.0 ) | 39.6 - ( 18.0 ) |
We reserve the right to improve or withdraw the specification or products without prior notice.
