SPECIFICATIONS | MODEL F210 ( 4.7 HP ) | MODEL F300 ( 6.7 HP ) | MODEL F400 ( 10 HP ) |
Engine Type | Single cylinder 4 cycle air cooled, diesel | Single cylinder 4 cycle air cooled, diesel | Single cylinder 4 cycle air cooled, diesel |
Bore x Stroke mm ( inch ) | 70 x 55 - (2.75 x 2.16 ) | 78 x 62 - ( 3.07 x 2.44 ) | 86 x 70 - ( 3.38 x 2.75 ) |
Displacement cc | 211 | 296 | 406 |
Max output Hp | 3000 RPM @ 4.2 Hp, 3600 RPM @ 4.7 Hp |
3000 RPM @ 6.1 Hp, 3600 RPM @ 6.7 Hp |
3000 RPM @ 8.8 Hp, 3600 RPM @ 10 Hp |
Continuous output Hp | 3000 RPM @ 3.8 Hp, 3600 RPM @ 4.2 Hp |
3000 RPM @ 5.5 Hp, 3600 RPM @ 6 Hp |
3000 RPM @ 7.7 Hp, 3600 RPM @ 9 Hp |
Fuel consumption g/hp-h | 3000 RPM @ 209, 3600 RPM @ 218 |
3000 RPM @ 206, 3600 RPM @ 215 |
3000 RPM @ 206, 3600 RPM @ 215 |
Start mode | Recoil or electric starter | Recoil or electric starter | Recoil or electric starter |
Air cleaner | Dry element | Dry element and Oil bath | Dry element and Oil bath |
Fuel Tank Capacity liter ( Gal ) | 2.5 - ( 0.66 ) | 3.5 - ( 0.92 ) | 5.5 - ( 1.45 ) |
Engine Oil Capacity liter ( Gal ) | 0.75 - ( 0.19 ) | 1.1 - ( 0.29 ) | 1.65 - ( 0.43 ) |
Dimensions L x W x H mm ( inch ) | 332 x 392 x 416 ( 13.07 x 15.43 x 16.37 ) |
383 x 421 x 450 ( 15.07 x 16.57 x 17.71 ) |
417 x 470 x 494 ( 16.41 x 16.50 x 19.94 ) |
Dry Weight recoil starter kg ( Lb ) | 27 - ( 59.52 ) | 33 - ( 72.75 ) | 48 - ( 105.82 ) |
Dry Weight elect starter kg ( Lb ) | 32 - ( 70.54 ) | 38 - ( 83.77 ) | 53 - ( 116.84 ) |
Also available conical shaft and thread shaft.
We reserve the right to improve or withdraw the specification or products without prior notice.
