| SPECIFICATIONS | MODEL PW2700D | MODEL PW3600D | |
ENGINE |
Model | Kapa F300 | Kapa F400 |
| Displacement cc | 296 | 406 | |
| Type | Single cylinder 4 cycle air cooled, diesel | Single cylinder 4 cycle air cooled, diesel | |
| Max output hp/rpm | 6.7 hp / 3600 rpm | 10 hp / 3600 rpm | |
| Start mode | Recoil and Electric | Recoil and Electric | |
| Fuel tank capacity L ( Gal ) | 3.5 Lit - ( 0.92 Gal ) | 5.5 Lit - ( 1.45 Gal ) | |
| Fuel continuos time /hour | 4-5 | 4 | |
PUMP |
Pressure | 2700 PSI | 3600 PSI |
| Flow rate Gal ( Lts/ min ) | 3.0 GPM ( 12.6 L/ min ) | 4.5 GPM ( 18.2 L/ min ) | |
| Drive Method | Direct | Direct | |
| Hose Feet ( Mts ) | 32.8 feet (10 Mts ) with interchangeable nozzles | 32.8 feet (10 Mts ) with interchangeable nozzles | |
UNIT |
Dimensions Lx W x H mm ( Inch ) | 785 x 640 x 655 - ( 30.9” x 25.2” x 28.78” ) | 810 x 730 x 780 - ( 31.9” x 28.7” x 30.7” ) |
| Dry weight Kg ( Lb ) | 65 - ( 144 Lb ) | 99 - ( 218 Lb ) |
We reserve the right to improve or withdraw the specification or products without prior notice.
