Gasoline Generator Model KJ3000 |
 |
|
||||
|
|
||||
Gasoline Generator Model KJ3000 |
| SPECIFICATIONS | MODEL KJ3000 | |
| GENERATOR | Type | Brush, Revolving Magnetic Field, 2 Poles – Single Phase |
| Frame | Ø 32mm Steel Tube | |
| Rate AC Output | 2.5 Kw / 2.8 Kw | |
| Max Ac Output | 2.8 Kw / 3.2 Kw | |
| Frequency | 50Hz / 60 Hz | |
| Voltage | 110 / 120 – 220 / 240V | |
| Voltage regulator | AVR System | |
| Power Factor | 1.0 | |
| ENGINE | Model | Kapa 168F-2 / 6.5 Hp |
| Type | 4 Stroke, Air Cooled, OHV, Single Cylinder | |
| Bore x Stroke mm ( Inch ) | 68 x 54 mm ( 2.67 x 2.12 inch ) | |
| Displacements | 196 ml | |
| Recommended fuel | Unleaded Gasoline | |
| Fuel tank capacity Lit ( Gal ) | 16 Lit ( 4.22 Gal ) | |
| Fuel consumption | ≤ 395g / Kw - hour | |
| Engine oil capacity Lit ( Gal ) | 0.6 Lit ( 0.16 Us qt ) | |
| Start Mode | Recoil and electric starter | |
| STANDARD FEATURES |
Oil alert | yes |
| Fuel gauge | yes | |
| Ac voltmeter | yes | |
| Ac circuit breaker | yes | |
| Electric starter | yes | |
| DC socket ( 12V/8.3 Amp ) | yes | |
| DC circuit breaker | yes | |
| Battery 12V | yes | |
| Handle | yes | |
| Wheels | yes | |
| SET | Cont working time | 9 – 10 Hours |
| Noise Level @ 7 meters ( 22.9 feet ) | 67 dB ( A ) | |
| Packing dimension L x W x H mm ( inch ) | 655 x 485 x 440 mm ( 25.79 x 19.09 x 17.32 inch ) | |
| Net weight Kg ( Lb ) | 47 Kg ( 103.6 Lb ) | |
| Gross weight kg ( Lb ) | 49 Kg ( 108 Lb ) |
We reserve the right to improve or withdraw the specification or products without prior notice.
