| SPECIFICATIONS | MODEL PW2700K | MODEL PW3000K | MODEL PW3200K | MODEL PW3600K | |
ENGINE |
Model | Kapa 168F2 | Kapa 173F | Kapa 177F | Kapa 188F |
| Displacement cm3 ( cu inch ) |
196 cm3 (17.7 cu in) |
242 cm3 ( 14.8 cu in ) | 242 cm3 ( 14.8 cu in ) | 389 cm3 ( 23.7 cu/in ) | |
| Type | Single cylinder 4 cycle air cooled, diesel | Single cylinder 4 cycle air cooled, diesel | Single cylinder 4 cycle air cooled, diesel | Single cylinder 4 cycle air cooled, diesel | |
| Max output hp/rpm | 6.5 HP @ 3,600 rpm | 8.0 HP @ 3,600 rpm | 9.0 HP @ 3,600 rpm | 13.0 HP @ 3,600 rpm | |
| Start mode | Recoil | Recoil | Recoil | Recoil & Electric | |
| Fuel Tank Capacity liter ( Gal ) | 3.6 Lit ( 0.95 Gal ) | 6 Lit ( 1.58 Gal ) | 6 Lit ( 1.58 Gal ) | 6.5 Lit ( 1.71 Gal ) | |
| Fuel continuos time / hour | 3-4 | 4-5 | 4-5 | 4-5 | |
PUMP |
Pressure | 2700 PSI | 3000 PSI | 3200 PSI | 3600 PSI |
| Flow rate Gal / min ( Lts/min ) | 3.0 GPM ( 12.6 L/ min ) | 4.0 GPM ( 15.0 L/ min ) | 4.0 GPM ( 15.0 L/ min ) | 4.5 GPM ( 18.2 L/ min ) | |
| Drive Method | Direct | Direct | Direct | Direct | |
| Hose Feet ( Mts ) | 32.8 feet (10 Mts ) with interchangeable nozzles | 32.8 feet (10 Mts ) with interchangeable nozzles | 32.8 feet (10 Mts ) with interchangeable nozzles | 32.8 feet (10 Mts ) with interchangeable nozzles | |
UNIT |
Tire | 14” Pneumatic | 14” Pneumatic | 14” Pneumatic | 14” Pneumatic |
| Dimensions Lx W x H mm ( Inch ) |
785 x 640 x 655 ( 30.9” x 25.2” x 28.78” ) |
785 x 640 x 655 ( 30.9” x 25.2” x 28.78” ) |
785 x 640 x 655 ( 30.9” x 25.2” x 28.78” ) |
785 x 640 x 655 ( 30.9” x 25.2” x 28.78” ) |
|
| Dry weight Kg ( Lb ) | 49 - (107 Lb ) | 65 - (143 Lb ) | 65 - 143 Lb ) | 68 - (150 Lb ) |
We reserve the right to improve or withdraw the specification or products without prior notice.
