CORMAC, INC. Construction Equipment

Rugged and powerful generators for the most demanding jobsites

Designed for construction rental and other demanding applications, these high performance, portable generators deliver unmatched tool starting and voltage regulation in a rugged, compact package. Built the Wacker Neuson way, with heavy-duty frames and premium components to provide long, trouble-free operation even in abusive environments. Ideal for powering high starting amperage tools such as compressors, grinders, fusion welders, saws, pressure washers as well as all of your Wacker Neuson electric- powered pumps, breakers, drills, concrete vibrators, etc.

Best in class tool starting and voltage regulation due to unique step-start generator technology with AVR (automatic voltage regulation) and separate excitation winding.
Unique GFCI (neutral bonded to ground) sensor system eliminates common GFI outlet failures while offering personal protection on all receptacles including 240 Volt. Meets the latest NEC and OSHA jobsite standards.
Full wrap-around frame with dual cross-member support, high impact polyethylene fuel tank and heavy duty shock-mounting combine to provide outstanding impact protection.
A super quiet muffler allows for versatile operation.
Unique auto-idle control with time delay system automatically reduces the engine to a low speed reducing fuel consumption, noise and wear.
The folding central lifting eye and integrated wheel kit make these compact generators easy to transport and store.
Full power switch for maximum 120V power output or 120V/240V power.
Features reliable Honda OHV engine with low oil shutdown.

SPECIFICATIONS	GP 4000	GP 5600A/ GP5600A w/wheels kit GPS 5600A	GP 6600A/ GP 6600A w/wheels kit GPS 6600A
Length x width x height in ( cm )	27 x 21 x 21.2 - ( 68.6 x 53.3 x 53.8 )	27 x 21 x 21.2 ( 68.6 x 53.3 x 53.8 ) 39.5 x 27 x 26.7 ( 100.3 x 68.6 x 67.8 ) 34.3 x 21 x 21.2 ( 87.1 x 53.3 x 53.8 )	27 x 21 x 21.2 ( 68.6 x 53.3 x 53.8 ) 39.5 x 27 x 26.7 ( 100.3 x 68.6 x 67.8 ) 34.3 x 21 x 21.2 ( 87.1 x 53.3 x 53.8 )
Dry weight lbs ( Kg )	152 - ( 68.94 )	186 - ( 84.36 ) 208 - ( 94.34 ) 201 - ( 91.17 )	192 - ( 87.08 ) 213 - ( 96.61 ) 206.5 - ( 93.66 )
Shipping size l x w x h in ( cm )	28 x 21.5 x 23.2 - ( 71.1 x 54.6 x 58.9 )	28 x 21.5 x 23.2 ( 71.1 x 54.6 x 58.9 ) 28 x 27 x 23.2 ( 71.1 x 68.6 x 58.9 ) 28 x 27 x 23.2 ( 71.1 x 68.6 x 58.9 )	28 x 21.5 x 23.2 ( 71.1 x 54.6 x 58.9 ) 28 x 27 x 23.2 ( 71.1 x 68.6 x 58.9 ) 28 x 27 x 23.2 ( 71.1 x 68.6 x 58.9 )
Shipping weight lb ( kg )	157 - ( 71.21 )	191 - ( 86.63 ) 213 - ( 96.61 ) 206 - ( 93.44 )	197 - ( 89.35 ) 218 - ( 98.88 ) 212 - ( 96.16 )
Maximum output W	4000	5600	6600
Continuous output W	3600	5000	6000
Continuous AC amps A	30/15	41.7/20.8	50/25
AC voltage V	120/240	120/240	120/240
AC circuit breaker amps A	17	23	27
Frequency Hz	60	60	60
Phase Ø	1	1	1
Power factor Pf	1	1	1
Engine type	Air cooled, 4 cycle, single cylinder, gasoline engine Wacker Neuson	Air cooled, 4 cycle, single cylinder, gasoline engine Honda	Air cooled, 4 cycle, single cylinder, gasoline engine Honda
Starting system	Recoil	Recoil Recoil 12V Electric	Recoil Recoil 12V Electric
Displacement in³	16.2	20.6	23.7
Operating speed rpm	3600	3600	3600
Max rated power hp @ rpm	9 @ 3600	9.5 @ 4000	11 @ 3600
Power rating specification	SAE J1349	SAE J1349	SAE J1349
Fuel tank capacity gal ( lit )	5.2 - ( 19.68 )	5.2 - ( 19.68 )	5.2 - ( 19.68 )
Running time/full load hrs	8.3	6	5
Ac receptables	2-125V, 20 A duplex GFCI, 1-125V. 30A Twist-lock 1-125/250V, 30A Twist-lock

We reserve the right to improve or withdraw the specification or products without prior notice.
