SPECIFICATIONS | CRT 36-24A/with wheels kit | CRT 36-25/with wheels kit | CRT 48-35V | CRT 48-34V | CRT 48-35L |
Length x width s height inch ( cm ) |
80 x 41 x 54 ( 203.2 x 104.1 x 137.2 ) |
80 x 41 x 54 ( 203.2 x 104.1 x 137.2 ) |
101 x 51 x 58 ( 256.5 x 129.5 x 147.3 ) |
101 x 51 x 58 ( 256.5 x 129.5 x 147.3 ) |
101 x 51 x 58 ( 256.5 x 129.5 x 147.3 ) |
Operating weight lbs ( Kg ) | 830/865 ( 376.48 / 392.35 ) |
835/870 |
1130 ( 512.55 ) | 1240 ( 532.45 ) | 1340 ( 607.81 ) |
Shipping size l x w x h inch ( cm ) |
86x 45 x 63.5 ( 218.4 x 114.3 x 161.3 ) |
86x 45 x 63.5 ( 218.4 x 114.3 x 161.3 ) |
107x 55.75 x 64 ( 271.8 x 141.6 x 162.6 ) |
107x 55.75 x 64 ( 271.8 x 141.6 x 162.6 ) |
107x 55.75 x 64 ( 271.8 x 141.6 x 162.6 ) |
Shipping weight lbs ( Kg ) | 1050/1085 ( 476.27 / 492.14 ) | 1055/1090 ( 478.53 / 494.41 ) | 1470 ( 666.78 ) | 1580 ( 716.67 ) | 1680 ( 762.03 ) |
Trowel diameter inch ( cm ) | 36 ( 91.4 ) | 36 ( 91.4 ) | 48 ( 121.9 ) | 48 ( 121.9 ) | 48 ( 121.9 ) |
Number of blades | 8 | 8 | 10 | 10 | 10 |
Combination blade size inch ( cm ) |
14 x 8 ( 35.6 x 20.3 ) | 14 x 8 ( 35.6 x 20.3 ) | 18 x 8 ( 45.7 x 20.3 ) | 18 x 8 ( 45.7 x 20.3 ) | 18 x 8 ( 45.7 x 20.3 ) |
Finish blade size inch ( cm ) | 14 x 6 ( 35.6 x 15.2 ) | 14 x 6 ( 35.6 x 15.2 ) | 18 x 6 ( 45.7 x 15.2 ) | 18 x 6 ( 45.7 x 15.2 ) | 18 x 6 ( 45.7 x 15.2 ) |
Float blade size inch ( cm ) | 14 x 10 ( 35.6 x 25.4 ) | 14 x 10 ( 35.6 x 25.4 ) | 18 x 10 ( 45.7 x 25.4 ) | 18 x 10 ( 45.7 x 25.4 ) | 18 x 10 ( 45.7 x 25.4 ) |
Speed range rpm | 25 - 165 | 25 - 165 | 25 - 165 | 25 - 165 | 25 - 165 |
Pitch range degrees | 0 - 25 | 0 - 25 | 0 - 25 | 0 - 25 | 0 - 25 |
Engine type | Air cooled, 4 cycle Gasoline engine Honda | Air cooled, 4 cycle Gasoline engine Wacker Neuson | Air cooled, 4 cycle V-twin Gasoline engine Briggs & Stratton Vanguard | Air cooled, 4 cycle 3 cylinder Gasoline engine Briggs & Stratton Vanguard | Liquid cooled, 4 stroke, 4 cylinders Lombardini engine |
Operating speed rpm | 3850 | 3850 | 3800 | 3800 | 3800 |
Max rated power hp@rpm | 20.5@3600 | 25@3600 | 35@3800 | 34@3800 | 32.9@3800 |
Power rating specification | SAE J1349 | SAE J1349 | SAE J1995 | SAE J1995 | NB ISO 3046 IFN |
Piston displacement in³ | 41 | 44 | 61 | 58 | 84 |
Fuel tank capacity qt ( lt ) | 6.5 ( 6.15 ) | 6.5 ( 6.15 ) | 6.5 ( 6.15 ) | 6.5 ( 6.15 ) | 6.5 ( 6.15 ) |
Fuel consumption qt/h ( lt/h ) |
2.4 ( 2.27 ) | 2.4 ( 2.27 ) | 2.75 ( 2.60 ) | 2.75 ( 2.60 ) | 1.6 ( 1.51 ) |
We reserve the right to improve or withdraw the specification or products without prior notice.
