Trowels feature high quality finishing plus triple protection

Designed and built with the most advanced technology, Wacker’s walk-behind trowels offer high quality concrete finishing plus added operator safety. The patent-pending gearbox brake, gyroscopic safety sensor and engine speed limiter provide triple protection for the operator. This unique system minimizes a runaway handle situation and meets worldwide safety requirements.

  • Dynamically balanced trowels (when blades are turning) offer nearly effortless operation.
  • Optimum weight distribution reduces the lateral force from the trowel for reduced operator fatigue.
  • Trowels feature a 30-degree blade pitch for better concrete burnishing.
  • For maximum flexibility, engine type, trowel diameter and handle type can be selected to meet individual preferences or job site conditions. (Handle sold separately).
  • Guard ring features tubular framing for easy cleaning and maintenance.
SPECIFICATIONS CT 36-5A CT 36-6 CT 48-8A CT 48-9
Length x width s height
inch ( cm )		 79 x 36 x 41
( 200.7 x 91.4 x 104.1  )		 79 x 36 x 36
( 200.7 x 91.4 x 91.4  )		 85 x 48 x 41
( 215.9 x 121.9 x 104.1  )		 85 x 48 x 41
( 215.9 x 121.9 x 104.1  )
Operating weight lbs ( Kg ) 183 - ( 83  ) 183 - ( 83  ) 234 - ( 106.14  ) 227 - ( 102.96  )
Shipping weight lbs ( Kg ) 220 - ( 99.79  ) 220 - ( 99.79  ) 284 - ( 128.82  ) 277 - ( 125.64  )
Shipping size l x w x h inch ( cm ) 41 x 40 x 29
( 104.1 x 101.6 x 73.7 )		 41 x 40 x 29
( 104.1 x 101.6 x 73.7		 51 x 46 x 43
( 129.5 x 116.8 x 109.2 )		 51 x 46 x 43
( 129.5 x 116.8 x 109.2 )
Storage size l x w x h inch ( cm ) 38 x 24 x 34
( 96.5 x 61 x 86.4 )		 38 x 24 x 34
( 96.5 x 61 x 86.4 )		 38 x 24 x 34
( 96.5 x 61 x 86.4 )		 38 x 24 x 34
( 96.5 x 61 x 86.4 )
Trowel diameter inch ( cm ) 36 - ( 91.4 ) 36 - ( 91.4 ) 48 - ( 122 ) 48 - ( 122 )
Number of blades 4 4 4 4
Speed range  rpm 60 - 125 60 - 125 60 - 125 60 - 125
Finish blade size inch ( cm ) 9 x 4.75 - ( 22.9 x 12.1 ) 9 x 4.75 - ( 22.9 x 12.1 ) 9 x 4.75 - ( 22.9 x 12.1 ) 9 x 4.75 - ( 22.9 x 12.1 )
Float blade size inch ( cm ) 23.8 - ( 60.5 ) 23.8 - ( 60.5 ) 23.8 - ( 60.5 ) 23.8 - ( 60.5 )
Pitch range  degrees 0 - 30 0 - 30 0 - 30 0 - 30
Engine type Air cooled, 4 cycle Gasoline engine Honda Air cooled, 4 cycle Gasoline engine Wacker Neuson Air cooled, 4 cycle Gasoline engine Honda Air cooled, 4 cycle Gasoline engine Wacker Neuson
Operating speed  rpm 3800 3800 3800 3800
Max rated power hp@rpm 4.8@3600 5.7@4000 7.1@3600 9@4000
Power rating specification SAE J1349 SAE J1349 SAE J1349 SAE J1349
Piston displacement in³ 9.9 10.4 14.8 16.2
Hprsepower   Hp 5.5 5.6 8 9
Fuel tank capacity qt ( lt ) 3.8 - ( 3.59 ) 3.8 - ( 3.59 ) 6.4 - ( 6.05 ) 6.4 - ( 6.05 )
Fuel consumption qt/h ( lt/h ) 1.9 - ( 1.79 ) 1.6 - ( 1.51 ) 2.8 - ( 2.64 ) 2.6 - ( 2.46 )

We reserve the right to improve or withdraw the specification or products without prior notice.
