SPECIFICATIONS | VP 2050 / VP 2050W | VP 2050A / VP 2050AW | VP 2050Y |
Operating weight Lbs ( Kg ) | 230 - ( 104.54 ) 233 - ( 105.90 ) |
230 - ( 104.54 ) 233 - ( 105.90 ) |
250 - ( 113.63 ) |
Shipping weight Lbs ( Kg ) | 235 - ( 106.81 ) 240 - ( 109.09 ) |
235 - ( 106.81 ) 240 - ( 109.09 ) |
260 - ( 118.18 ) |
Lowest operating height Inch ( cm ) | 27 - ( 68.6 ) | 27 - ( 68.6 ) | 26 - ( 66 ) |
Size of base plate w x l Inch ( cms ) | 19.5 x 23 - ( 49.5 x 58.4 ) | 19.5 x 23 - ( 49.5 x 58.4 ) | 19.5 x 23 - ( 49.5 x 58.4 ) |
Shipping size l x w x h Inch ( cm ) | 29 x 22 x 33 - ( 73.7 x 55.9 x 83.8 ) | 29 x 22 x 33 - ( 73.7 x 55.9 x 83.8 ) | 29 x 22 x 33 - ( 73.7 x 55.9 x 83.8 ) |
Max forward travel depending on soil Ft/min ( mt/min ) |
80 - ( 24.38 ) | 80 - ( 24.38 ) | 80 - ( 24.38 ) |
Max forward travel depending on asphalt Ft/min ( mt/min ) | -/88 - ( 26.82 ) | -/88 - ( 26.82 ) | na |
Max compacted area depending on soil Ft²/h ( mt²/h ) | 7880 - ( 732.07 ) | 7880 - ( 732.07 ) | 7880 - ( 732.07 ) |
Max compacted area depending on asphalt Ft²/h ( mt²/h ) | -/8694 - ( 807.69 ) | -/8694 - ( 807.69 ) | na |
Max Gradeability on soil % | 30% | 30% | 30% |
Vibration frequency Vpm | 5800 | 5800 | 5800 |
Centrifugal force Lbs ( kg ) | 4500 - ( 2045 ) | 4500 - ( 2045 ) | 4500 - ( 2045 ) |
Engine Type | Air cooled, 4 cycle, single cylinder, Gasoline engine Wacker Neuson | Air cooled, 4 cycle, single cylinder, Diesel engine Yanmar | |
Displacement in³ | 10.3 | 9.9 | 13.36 |
Max rated power Hp @ rpm | 5.7 @ 4000 | 4.8 @ 3600 | 4.7@ 3600 |
Power rating specification | SAE J1995 | SAE J1349 | na |
Water tank capacity Qt ( lt ) | -/8 - ( 7.57 ) | -/8 - ( 7.57 ) | - |
Fuel consumption qt/h ( lt/h ) | 1.6 - ( 1.51 ) | 1.9 - ( 1.76 ) | 1.0 - ( 0.94 ) |
Fuel tank capacity Qt ( lts ) | 3.8 - ( 3.59 ) | 3.8 - ( 3.59 ) | 2.54 - ( 2.40 ) |
We reserve the right to improve or withdraw the specification or products without prior notice.
