| SPECIFICATIONS | MODEL 168F ( 5.5 HP ) |
MODEL 168F-2 ( 6.5 HP ) |
MODEL 173F ( 8 HP ) |
MODEL 177F ( 9 HP ) |
MODEL 182F ( 11 HP ) |
MODEL 188F ( 13 HP ) |
| Engine Type | Air-cooled, single cylinder, 4-Stroke, OHV | Air-cooled, single cylinder, 4-Stroke, OHV | Air-cooled, single cylinder, 4-Stroke, OHV | Air-cooled, single cylinder, 4-Stroke, OHV | Air-cooled, single cylinder, 4-Stroke, OHV | Air-cooled, single cylinder, 4-Stroke, OHV |
| Bore x Stroke mm ( inch ) |
68 x 45 mm (2.67 x 1.77 in) |
68 x 54 mm ( 2.67 x 2.12 in ) |
73 x 58 mm ( 2.9 x 2.3 in ) |
77 x 58 mm ( 3.03 x 2.28 in ) |
82 x 64 mm ( 3.22 x 2.52 in ) |
88 x 64 mm ( 3.46 x 2.52 in ) |
| Displacement cm3 ( cu inch ) |
163 cm3 (14.8 cu in) |
196 cm3 (17.7 cu in) |
242 cm3 ( 14.8 cu in ) |
270 cm3 ( 16.5 cu/in ) |
389 cm3 ( 23.7 cu/in ) |
389 cm3 ( 23.7 cu/in ) |
| Compression Ratio | 8: 5 : 1 | 8: 5 : 1 | 8: 2 : 1 | 8: 2 : 1 | 8: 1 | 8: 1 |
| Max Power Output ( 3600 rpm ) |
5.5 HP at 3,600 rpm | 6.5 HP at 3,600 rpm | 8 HP at 3,600 rpm | 9 HP at 3,600 rpm | 11 HP at 3,600 rpm | 13 HP at 3,600 rpm |
| Max Torque ( 2500 rpm ) |
1.1 Kg.m @ 2,500 rpm |
1.35 Kg.m @ 2,500 rpm | 1.7 Kg.m @ 2,500 rpm | 1.95 Kg.m @ 2,500 rpm | 2.4 Kg.m @ 2,500 rpm | 2.7 Kg.m @ 2,500 rpm |
| Ignition System | Non – contact transistorized ignition ( TCL ) |
Non – contact transistorized ignition ( TCL ) |
Non – contact transistorized ignition ( TCL ) |
Non – contact transistorized ignition ( TCL ) |
Non – contact transistorized ignition ( TCL ) |
Non – contact transistorized ignition ( TCL ) |
| Start mode | Recoil Starter | Recoil Starter | Recoil Starter | Recoil and electric starter | Recoil and electric starter | Recoil and electric starter |
| Air cleaner | Semi dry, oil bath, dual, double silent and cyclone type | Semi dry, oil bath, dual, double silent and cyclone type | Semi dry, oil bath, dual, double silent and cyclone type | Semi dry, oil bath, dual, double silent and cyclone type | Semi dry, oil bath, dual, double silent and cyclone type | Semi dry, oil bath, dual, double silent and cyclone type |
| Fuel Tank Capacity liter ( Gal ) |
3.6 Lit ( 0.95 Gal ) |
3.6 Lit ( 0.95 Gal ) |
6 Lit ( 1.58 Gal ) |
6 Lit ( 1.58 Gal ) |
6.5 Lit ( 1.71 Gal ) |
6.5 Lit ( 1.71 Gal ) |
| Engine Oil Capacity liter ( Gal ) |
0.6 Lit ( 0.16 US qt ) |
0.6 Lit ( 0.16 US qt ) |
1.1 Lit ( 1.16 US qt ) |
1.1 Lit (1.16 US qt ) |
1.1 Lit ( 1.16 US qt ) |
1.1 Lit (1.16 US qt) |
| Dimensions L x W x H ( inch ) |
425mm x 380mm x 390mm (16.7x14.96x15.35 in ) |
425mm x 380mm x 390mm (16.7x14.96x15.35 in ) |
490mm x 455mm x 505mm (19.9x7.9x9.88 in) |
490mm x 455mm x 505mm (19.9x17.9x19.88in ) |
485mm x 460mm x 525mm (19x18.1x 20.67 in ) | 485mm x 460mm x 525mm (19 x 18.1 x 20.67 in ) |
| Dry Weight kg ( Lb ) |
15 ( 33 ) |
16 ( 33.06 ) |
25 ( 55.11 ) |
25 ( 55.11 ) |
31 ( 68.34 ) |
31 ( 68.34 ) |
Also available conical shaft and thread shaft
We reserve the right to improve or withdraw the specification or products without prior notice.
