INVERTER DC TO AC 2000 WATTS WITH CHARGER
INVERTER DC TO AC 3000 WATTS WITH CHARGER
INVERTER DC TO AC 5000 WATTS WITH CHARGER
INVERTER DC TO AC 2000 WATTS WITH CHARGER
Introduction：
- For use in car, boats, trucks, trailers and mobile homes.
- Take the power inverter to portable and get power to run lamps, radios or TVs.
- In an emergency such as blackout, attach the power inverter to your car battery or portable battery and get power to run your appliances.
- Ultra-Compact Metal Housing: Small and rugged: stored easily in any tool box, briefcase or glove compartment.
- Integrated Fuse Protection: Protects your battery and power inverter from damage due to outlet overload.
- The inverter can automatically detect low battery voltage and shut down to preserve the battery
- Overload protection: shutdown and alarm (integrated fuse protection, protects the battery, and power inverter from damage due to outlet overload)
- Output short: output short circuit protection.
- Battery protection reverse: By fuse.
- Short circuit protection and no spark clamps
- Thermal and current overload protection
- Automatic switch / Transfer time: AC line to inverter, inverter to AC line, transfer 10ms.
- Compliant standards: CB, CE, E13, IEC60950, EN61000
Inverter Function:
- DC input voltage: 12V DC, 183A, (10-15V)
- Input standby current (12V DC,+/-5%): ≤0.7A
- AC output voltage: 230V AC / 110V AC, +/-8%
- Output power: 2000W, 8.7A
- Output power (peak watts): 4000W
- Output frequency: 50 or 60Hz
- Output waveform: Modified sine wave
- Low-battery voltage alarm: 10.5V DC,+/-0.5V
- Low-battery voltage shutdown: 10.0V DC, +/-0.5V
- Fuse quantity & size: 25A×12 , Standard auto blade fuse (Internal*)
- Efficiency: 85 to 90%
- Thermal shutdown: 65℃+/-5℃
- Cooling fan: Yes auto-operation fan (temperature or load)
- Connection cable: 25.0mm2 / 1100mm.
Charger Function:
- Rated input voltage: 230V AC, (160-270V), 50Hz / 110V AC, (80-130V), 60Hz.
- Input power: 2.65A
- Rated output: 12V DC, 20,000mA
- Minimum start voltage: 4.5V
- Current fuse rating: 250V AC, F3.15A, (Internal*), T10A, (External), 5×20mm.
- Type: 3 Stage automatic
- Charge control: Bulk 20,000mA (up to 14.7V), Absorption 14.4V, Float 13.8V.
- Battery range: 85-400Ah
- Battery Type: For charging 12V lead acid batteries only.
- Thermal protect (fan on): 65℃+/-5℃.
- Cooling fan: Automatic temperature controlled.
- Performance: Micro-processing switching mode.
- Efficiency: App. 85%.
- Operating temperature: 0~40℃
- Storage temperature:: -15℃~45℃
- Operating relative humidity: 10%RH~102%RH,
- Machine size(mm): 525×242×76
- N.W.(Kgs): 5.8Kg
top
INVERTER DC TO AC 3000 WATTS WITH CHARGER
Introduction：
- For use in car,boats,trucks,trailers and mobile homes.
- Take the power inverter to portable and get power to run lamps, radios or TVs.
- In an emergency such as blackout, attach the power inverter to your car battery or portable battery and get power to run your appliances.
- Ultra-Compact Metal Housing: Small and rugged: stored easily in any tool box, briefcase or glove compartment.
- Integrated Fuse Protection: Protects your battery and power inverter from damage due to outlet overload.
- The inverter can automatically detect low battery voltage and shut down to preserve the battery
- Overload protection: shutdown and alarm (integrated fuse protection, protects the battery, and power inverter from damage due to outlet overload)
- Output short: output short circuit protection.
- Battery protection reverse: By fuse.
- Short circuit protection and no spark clamps
- Thermal and current overload protection
- Automatic switch / Transfer time: AC line to inverter, inverter to AC line, transfer 10ms.
- Compliant standards: CE, EN60950, EN61000
Inverter Function:
- DC input voltage: 12V DC, 275A, (10-15V)
- Input standby current (12V DC,+/-5%): ≤0.75A
- AC output voltage: 230V AC / 110V AC, +/-8%
- Output power: 3000W, 13.1A
- Output power (peak watts): 6000W
- Output frequency: 50 or 60Hz
- Output waveform: Modified sine wave
- Low-battery voltage alarm: 10.5V DC,+/-0.5V
- Low-battery voltage shutdown: 10.0V DC, +/-0.5V
- Fuse quantity & size: 25A×18, Standard auto blade fuse (Internal*)
- Efficiency: 85 to 90%
- Thermal shutdown: 65℃+/-5℃
- Cooling fan: Yes auto-operation fan (temperature or load)
- Connection cable: 35.0mm2 / 1100mm.
Charger Function:
- Rated input voltage: 230V AC, (160-270V), 50Hz / 110V AC, (80-130V), 60Hz.
- Input power: 2.75A
- Rated output: 12V DC, 20,000mA
- Minimum start voltage: 4.5V
- Current fuse rating: 250V AC, F3.15A, (Internal*), T10A, (External), 5×20mm.
- Type: 3 Stage automatic
- Charge control: Bulk 20,000mA (up to 14.7V), Absorption 14.4V, Float 13.8V.
- Battery range: 100-500Ah
- Battery Type: For charging 12V lead acid batteries only.
- Thermal protect (fan on): 65℃+/-5℃.
- Cooling fan: Automatic temperature controlled.
- Performance: Micro-processing switching mode.
- Efficiency: App. 85%.
- Operating temperature: 0~40℃
- Storage temperature:: -15℃~45℃
- Operating relative humidity: 10%RH~102%RH,
- Machine size(mm): 440×210×156
- N.W.(Kgs): 7.2Kg
top
INVERTER DC TO AC 5000 WATTS WITH CHARGER
Introduction：
- For use in car,boats,trucks,trailers and mobile homes.
- Take the power inverter to portable and get power to run lamps, radios or TVs.
- In an emergency such as blackout, attach the power inverter to your car battery or portable battery and get power to run your appliances.
- Ultra-Compact Metal Housing: Small and rugged: stored easily in any tool box, briefcase or glove compartment.
- Integrated Fuse Protection: Protects your battery and power inverter from damage due to outlet overload.
- The inverter can automatically detect low battery voltage and shut down to preserve the battery
- Overload protection: shutdown and alarm (integrated fuse protection, protects the battery, and power inverter from damage due to outlet overload)
- Output short: output short circuit protection.
- Battery protection reverse: By fuse.
- Short circuit protection and no spark clamps
- Thermal and current overload protection
- Automatic switch / Transfer time: AC line to inverter, inverter to AC line, transfer 10ms.
- Compliant standards: CE, EN60950, EN61000
Inverter Function:
- DC input voltage: 12V DC, 458A, (10-15V)
- Input standby current (12V DC,+/-5%): ≤0.9A
- AC output voltage: 230V AC / 110V AC, +/-8%
- Output power: 5000W, 21.8A
- Output power (peak watts): 10,000W
- Output frequency: 50 or 60Hz
- Output waveform: Modified sine wave
- Low-battery voltage alarm: 10.5V DC,+/-0.5V
- Low-battery voltage shutdown: 10.0V DC, +/-0.5V
- Fuse quantity & size: 25A×30, Standard auto blade fuse (Internal*)
- Efficiency: 85 to 90%
- Thermal shutdown: 65℃+/-5℃
- Cooling fan: Yes auto-operation fan (temperature or load)
- Connection cable: 70.0mm2 / 1100mm.
Charger Function:
- Rated input voltage: 230V AC, (160-270V), 50Hz / 110V AC, (80-130V), 60Hz.
- Input power: 2.95A
- Rated output: 12V DC, 20,000mA
- Minimum start voltage: 4.5V
- Current fuse rating: 250V AC, F3.15A, (Internal*), T10A, (External), 5×20mm.
- Type: 3 Stage automatic
- Charge control: Bulk 20,000mA (up to 14.7V), Absorption 14.4V, Float 13.8V.
- Battery range: 200-700Ah
- Battery Type: For charging 12V lead acid batteries only.
- Thermal protect (fan on): 65℃+/-5℃.
- Cooling fan: Automatic temperature controlled.
- Performance: Micro-processing switching mode.
- Efficiency: App. 85%.
- Operating temperature: 0~40℃
- Storage temperature:: -15℃~45℃
- Operating relative humidity: 10%RH~102%RH,
- Machine size(mm): 510×210×156
- N.W.(Kgs): 9.5Kg
