Wet screed offers both reliable performance and operator comfort Wacker Neuson's wet screed can fit the demands of every jobsite with a variety of blade lengths, plus each unit is designed to fit the demands of every operator. Its unique twin handle system is fully height and angle adjustable offering maximum operator comfort. In addition, two isolators reduce handle vibration to the operator. The squeeze-grip handle is also foldable for easy transport and storage. |
| SPECIFICATIONS | BTS 930L3 | BTS 935L3 | BTS 1030L3 | BTS 1035L3 |
| Length x width x height w/o guide cart in ( cm ) |
30.7 x 11.4 x 14.6 (77.97 x 28.96 x 37.08) |
31.5 x 11.4 x 14.6 ( 80.01 x 28.96 x 37.08) |
30.7 x 11.4 x 14.6 ( 77.97 x 28.96 x 37.08) |
31.5 x 11.4 x 14.6 ( 80.01 x 28.96 x 37.08) |
| Weight lb ( kg ) | 22 - ( 9.97 ) | 22.5 - ( 10.2 ) | 22 - ( 9.97 ) | 22.5 - ( 10.20 ) |
| Shipping size in ( cm ) | 27.6x 11.8 x 15.8 (70.10 x 29.97 x 40.13) |
27.6x 11.8 x 15.8 ( 70.10 x 29.97 x 40.13) |
27.6x 11.8 x 15.8 ( 70.10 x 29.97 x 40.13) |
27.6x 11.8 x 15.8 ( 70.10 x 29.97 x 40.13) |
| Shipping weight lb ( kg ) | 26 - ( 11.79 ) | 26.5 - ( 12.02 ) | 26 - ( 11.79 ) | 26.5 - ( 12.02 ) |
| Blade diameter in ( cm ) | 11.8 - ( 29.97 ) | 13.8 - ( 35.05 ) | 11.8 - ( 29.97 ) | 13.8 - ( 35.05 ) |
| Arbor diameter in ( cm ) | 0.8 - ( 2.03 ) | 1 - ( 2.54 ) | 0.8 - ( 2.54 ) | 1 - ( 2.54 ) |
| Nominal blade speed rpm | 4300 | 4300 | 4300 | 4300 |
| Max cutting depth in ( cm ) | 3.8 - ( 9.65 ) | 4.8 - ( 12.19 ) | 3.8 - ( 9.65 ) | 4.8 - ( 12.19 ) |
| Engine | Air cooled 2 cycle gasoline engine | Air cooled 2 cycle gasoline engine | Air cooled 2 cycle gasoline engine | Air cooled 2 cycle gasoline engine |
| Displacement in³ | 3.9 | 3.9 | 4.5 | 4.5 |
| Power output hp | 4.4 | 4.4 | 5.6 | 5.6 |
| Gasoline oil mixture | 50:1 | 50:1 | 50:1 | 50:1 |
| Fuel consumption qt/h ( lt/h ) | 2.2 - ( 2.08 ) | 2.2 - ( 2.08 ) | 2.9 - ( 2.74 ) | 2.9 - ( 2.74 ) |
| Tank capacity qt/lt | 1.2 - ( 1.13 ) | 1.2 - ( 1.13 ) | 1.2 - ( 1.13 ) | 1.2 - ( 1.13 ) |
We reserve the right to improve or withdraw the specification or products without prior notice.
